JWinsulators
Density(20±2℃): ≧2.1g/cm3
Water Absorption rate: ≤0.05%
HBa Hardness (side): 65HBa~75HBa
We can supply all kinds of insulation poles for HV switches, surge arresters, etc.
There are five types:
1.Insulation poles with thread.
2.Insulation poles crimped with metal fittings;
3.Insulation poles with silicone rubber housing and metal fittings.
4.Insulation poles with wear-resistant material housing and metal fittings.
5.Insulation poles with UV resistant protection layers.
We can design and manufacture different kinds of insulation poles according to customers’ requirements.
| Visual and dimensional examinations | Roundness ≤0.02 |
| Tolerance -0.02mm~0.03mm (rod diameter ≤30mm) | |
| Tolerance ±0.03mm (rod diameter >30mm) | |
| No scratch and damage,depth exceeding 0.15mm,No knot and skip of yarn,Surface is smooth and no Bubble,no internal cracks And scars | |
| Density(20±2℃) | ≧2.1g/cm3 |
| Water Absorption rate | ≤0.05% |
| HBa Hardness (side) | 65HBa~75HBa |
| Tensile strength | ≧1.100MPa |
| Bending strength | ≧900MPa |
| Inter-laminar shear strength | ≧35MPa |
| Torsion strength | ≧800MPa |
| Dye penetration test | ≧30min |
| Thermal induction （150℃±5℃，4hours) | No cracking,no bubble, No educts |
| Thermal Bending strength at 150℃±5℃，1hours | 280MPa~350MPa (within 5 min.) |
| Volume resistivity | ≥1.0×1010 Ω . m (140℃) |
| Lightning impulse withstand voltage (Dry) | ≥100KV(10mm) |
| Breakdown withstand voltage | ≥30kv/cm (DC) |
| ≥50KV/cm(AC) | |
| Vibration fatigue test (0.68 times/second) | 120.000 times |
| Glass fiber content | 78-82% |
| pitch of screw thread (for machining rod) | ≥2mm |
